KM-606-02

Feature：

1. Mechanical universal type.

2. Magnetic base with ON/OFF switch.

3. The arm is steel, the cylinder is aluminum alloy.

4. Dovetail groove for test indicators.

5. Clamp hole8mm(optional hole 3/8’’)

6. Overall stem length:350mm.

7. Tapped hole: M8×1.25mm.

8. Magnetic force: 60kg, base(LxWxH):58x50x55mm (Optional magnetic force:80kg, base(LxWxH):60x50x55mm）



Specification:

Order No.	Magnetic Force	Applicable Holding Stem Dia.	Base(L×W×H)
KM-606-02	60kg	?8mm, 3/8’’	58×50×55mm
